“The Lithrone GX40 advance will be the indispensable press for printing company management in this new age..”
Scroll down
LITHRONE GX40 advance
40-inch Offset Printing Press
Package solutions
The Lithrone GX40 advance is equipped with many features that are effective for various types of package printing
High performance
High productivity and print quality with easy operation
Long runs with heavy stock
High speed, automatic nonstop operation to handle long runs and deliver world-class performance in deluxe package printing
World Class ROI Printing Press
The Lithrone GX40 advance with its 41" sheet size and extra robust machine platform is the state of the art press for packaging applications. The "X" version of the press was specifically designed for increased speed and the additional wear and tear seen in the packaging market. With a max speed of 18,000 sph, and a wide stock range, it is the ideal machine for quality paper board applications needing high productivity and the lowest waste possible.
With Komori’s nonstop feeder and delivery, high rise material handling logistics, KHS-AI artificial intelligence and PQA-S sheet inspection systems, the GX40 is the ultimate high output press.
Advance Series
World Class ROI
The Lithrone GX/G advance series have been developed to provide customers with a world class ROI, with the highly advanced Lithrone sheetfed offset presses.
Connected Automation
Connected Automation, Komori’s concept for creating a Smart Factory, develops labour and work saving solutions, and strengthening standardization and inspection mechanisms.
Print Quality
The optimized dampening system, the dot quality sharpness and stability is maintained while suitability for high speed/long run printing is improved.
High Productivity and Profitability
The recent tide of rapid changes in the social and economic environment, major changes have been sought in the printing industry. Printing company management faces one of its most critical issues: to what extent can productivity in the printing process be raised.
The Lithrone GX/G advance series delivers high productivity and print quality with ease of operation. Based on the Connected Automation concept, strengthened collaboration and optimization between processes as well as high-level automation with presets based on information from high-end systems are realized, contributing to productivity improvement throughout the entire printing process.
| LITHRONE GX40 advance (40-inch Offset Printing Press) specifications | |||||||||
| Model | GLX-440A | GLX-540A | GLX-640A | GLX-740A | GLX-840A | ||||
| Numbers of colours | 4 | 5 | 6 | 7 | 8 | ||||
| Max printing speed | sph | 18,000 | |||||||
| Max sheet size | mm | 750 x 1,050 | |||||||
| Min sheet size | mm | 360 x 520 | |||||||
| Max printing area | mm | 740 x 1,040 | |||||||
| Sheet thickness range | mm | 0.06 ~ 1.0 | |||||||
| Plate size | mm | 811 x 1,055 | |||||||
| Blanket size | mm | 935 x 1,060 (including aluminum bar) | |||||||
| Feeder pile height | mm | 1,600 (plinth: 450) | |||||||
| Delivery pile height | mm | 1,600 (plinth: 450) | |||||||
| Dimensions | Length (L) | standard | mm | 13,557 | 14,735 | 15,913 | 17,091 | 18,269 | |
| standard with extended delivery | mm | 15,284 | 16,462 | 17,640 | 18,818 | 19,996 | |||
| standard with coater and extended delivery | mm | 16,462 | 17,640 | 18,818 | 19,996 | 21,174 | |||
| Width (W) | mm | 3,970 (5,770 with blower cabinet) | |||||||
| Height (H) | mm | 2,603 (3,084 with cover open, plinth: 450) | |||||||
* Total press length includes the feeder/delivery steps and the operation stand.
* Dimentions differ when options such as a double coater, drying unit, automatic non-stop feeder, or double delivery are selected.
* Maximum printing speed may differ depending on chosen specifications and printing conditions.
* Performance and numbers may differ from specifications herein, and specifications may also be modified for product improvements.
